Page 29
2. Installation
23
2.3 How to Install
This chapter explains how to install the actuator on your mechanical system.
2.3.1 General Rules on Installation
Follow the information below when installing the actuator, as a rule.
Do pay attention to these items (except with custom-order models).
{
: Possible u : Not possible
Horizontal
installation
Vertical
installation
Sideway
installation
Ceiling Mount
{
Ч
Ч
Ч
Installation Orientation
Horizontal
Vertical
Sideway
Ceiling Mount
