IAI America RCP2W-SA16C - Manual (Page 22)

1. Specifications Check
16
1.2.3 Driving System • Position Detector
Ball Screw Type
Motor Type Lead
No. of
Encoder
Pulses
Type Diameter Accuracy
8
86P
4
800 Rolled I 12 C10
1.2.4 Positioning repeatability
±0.08mm
* The values shown above are the accuracy at the delivery from the factory. It does not include the
consideration of time-dependent change as it is used.
1.2.5 Lost motion
0.7mm or less
* The values shown above are the accuracy at the delivery from the factory. It does not include the
consideration of time-dependent change as it is used.
