Ransburg, Table a low voltage cable lengths, Table b trigger type – Ransburg Vector R Series Cascade 79523 R90 Waterborne User Manual
Page 57: Cont.), Table c fluid delivery combination
Vector R Series Cascade Applicators - Parts Identification
Ransburg
53
44
18847-01
Fitting, Air Inlet, 1/4" NPSM(M) (Std.)
1
18847-00
Fitting, Air Inlet, 3/8" NPSM(M) (Optional)
1
45
Table A - "A2"
Cable, Low Voltage, Vector
Table A - "A1"
46
19749-00
Special Applicator Wrench
1
47
72315-00
Conductive Ferrule
1
48
6241-06
Fitting, Fluid
1
49
7787-03
Swivel Fitting
1
No Cable
10m
15m
20m
25m
30m
TABLE A
LOW VOLTAGE CABLE LENGTHS
--
79338-10
79338-15
79338-10
79338-10
79338-15
79338-15
"A2"
Description
0
1
1
2
1
1
2
"A1"
"A"
Dash #
0
1
2
3
4
5
2-Finger Trigger
4-Finger Trigger
79325-02
79325-04
"B1"
Description
2
4
"B"
Dash #
TABLE B
TRIGGER TYPE
"B2"
1
0
Item #
R90/70 CASCADE SOLVENTBORNE APPLICATOR -
PARTS LIST
(Figure 40)
(Cont.)
Part #
Description
Qty
1
2
3
4
5
6
7
Offset Bracket, .093" ID Fluid Tube
45
°
Bracket, .093" ID Fluid Tube
Offset Bracket (SS), .093" ID Fluid Tube
Offset Bracket, .250" ID Fluid Tube
45
°
Bracket, .250" ID Fluid Tube
Offset Bracket (SS), .250" ID Fluid Tube
Offset Bracket, .125" ID Coiled Fluid Tube
70399-00
70442-00
70399-00
70399-00
70442-00
70399-00
79650-00
"C1"
Description
"C"
Dash #
TABLE C
FLUID DELIVERY COMBINATION
79438-00
79439-00
79438-01
79438-00
79439-00
79438-01
79438-00
"C2"
10553-06
10553-06
10553-06
10553-06
10553-06
10553-06
10553-05
"C3"
9704-16
9704-16
9704-16
9704-11
9704-11
9704-11
79871-00
"C4"
1
1
1
1
1
1
0
"C5"
AH-06-01.13
