Vector R Series Cascade Applicators - Introduction
Ransburg
14
Fluid Flow
Capacity:
1000 cc/minute**
Operating Pressure (Air Spray)
Fluid:
(0-6.9 bar) 0-100 psi
Air:
(0-6.9 bar) 0-100 psi
Ambient Temp.:
40°C to 12.8°C
Consumption:
510 slpm (18 SCFM) @
3.4 bar (50 psig) inlet
Sound Level:
92dB (A) @ 50 psig inlet,
1m from applicator
** This reflects the maximum fluid volume the appli-
cator can deliver. The maximum spray volume that
can be effectively atomized depends on fluid rheol-
ogy, spray technology, and finish quality required.
Gun Length:
27cm (10.7 inches)
Weight:
735 grams (25.9 oz.)
Hose & Cable
Lengths (Std): 10m, 15m, 20m, 25m,
and 30m
Atomizer Nozzle
Assembly (Std):
79374-65, 79377-45
Operating Voltage: 85 kV DC (-) maximum
Current Output:
100 microamperes maximum
Paint Resistance:* .1 MW to
∞
*(Use Model No. 76652, Test Equipment)
Part Sprayability:
Determine sprayability of
part to be coated using
76652, Test Equipment
(See current "Paint, HV & SCI Test Equipment"
service manual.)
79500 R90 CASCADE
SOLVENTBORNE
SPECIFICATIONS
Environmental/Physical
Electrical
Mechanical
Fluid Flow
Capacity:
1000 cc/minute**
Operating Pressure (Air Spray)
Fluid:
(0-6.9 bar) 0-100 psi
Air:
(0-6.9 bar) 0-100 psi
Ambient Temp.:
40°C to 12.8°C
Consumption:
510 slpm (18 SCFM) @
3.4 bar (50 psig) inlet
Sound Level:
92dB (A) @ 50 psig inlet,
1m from applicator
** This reflects the maximum fluid volume the appli-
cator can deliver. The maximum spray volume that
can be effectively atomized depends on fluid rheol-
ogy, spray technology, and finish quality required.
Gun Length:
24cm (9.6 inches)
Weight:
650 grams (22.9 oz.)
Hose & Cable
Lengths (Std): 10m, 15m, 20m, 25m,
and 30m
Atomizer Nozzle
Assembly (Std):
79374-65, 79377-45
Operating Voltage: 65 kV DC (-) maximum
Current Output:
90 microamperes maximum
Paint Resistance:*
.1 MW to
∞
*(Use Model No. 76652, Test Equipment)
Part Sprayability:
Determine sprayability of
part to be coated using
76652, Test Equipment
(See current "Paint, HV & SCI Test Equipment"
service manual.)
79501 R70 CASCADE
SOLVENTBORNE
SPECIFICATIONS
Environmental/Physical
Electrical
Mechanical
