Version 5.0
Ultra Series UP Instruction Manual Gentec Electro-Optics Inc. All rights reserved
1
1 ULTRA SERIES UP POWER DETECTORS
1.1 INTRODUCTION
The Gentec-EO Ultra Series UP power detector family includes eleven series (XLP12, UP12E,
UP17P, UP19K, UP25N(M), UP25T, UP50N(M), UP55N(M), UP55C, UP60N(M), UP55G, and
UP60G) of opto-thermal sensors with different cooling options (stand alone, heat sink, fan and
water), with or without amplification. The high power surface absorber sensors are designed for use
at high average power densities.
The UP detectors are supplied with a 180 cm length flexible cable with output connection options of
a DB-15 "intelligent" male connector, an Integra USB connector, a BNC connector, a Molex
connector and a BNC/Molex connector. A few exception exist: the UP50N series is available with
BNC/Molex connector on special order only and the XLP12, UP60N(M), and UP60G series are only
supplied with a DB-
15 “intelligent” male connector and the Integra USB connector.
NOTE: To eliminate possible damage, do not carry the detector using the connector cable.
The UP detectors may also be supplied with a stand. Be aware that when using a detector with a
heat sink, the fins should always be placed vertically.
For cases where Gentec-
EO’s monitors don’t automatically read the wavelength correction factor,
you can use your det ector’s “Personal wavelength correction TM Certificate ” to adjust the power you
read to a power corrected for a particular wavelength.
Call your nearest Gentec-EO distributor to replace the sensor disk and/or to recalibrate the head.
For Gentec-
EO’s nearest office contact information, see p. ii, Contacting Gentec Electro-Optics
Inc.
Unit Aperture
Exterior
dimensions
Power range
mm mm (without amplification)
XLP12 12 73 x 73 1 µW to 3 W
UP12E 12 38 x 38 1 mW to 70 W
UP17P 17 46 x 46 1 mW to 6 W
UP19K,UP10K
(H5 ; H9 ; VR ; W5)
10 ; 19 ; 19 ; 18 ; 17 50 x 50 0.2 mW to 200 W
UP25N(M) 25 89 x 89 3 mW to 350 W
UP25T 25 62.4 x 62.4 10 mW to 250 W
UP50N(M) 50 89 x 89 5 mW to 50 W
UP55N(M) 55 89 x 89 5 mW to 700 W
UP55G 55 120 x 120 15 mW to 600 W
UP55C 55 116 X 116 0.2 W to 2500 W
UP60N(M) 60 89 x 89 5 mW to 700 W
UP60G 60 120 x 120 15 mW to 600 W
