UP12E-
…-H5-… 10S / 20H / 70W -H5
Without PCB
10S -H5
With PCB
Effective Aperture Diameter 12 mm
Spectral Range 0.19 – 20 µm
Calibrated spectral range a 0.248 – 2.5 µm and 10.6 µm
Power Noise Level 1 mW 0.25 mW
Typical Rise time (0-95%) 1.6 s (0.3 s with anticipation) 0.3 s (with anticipation)
Typical sensitivity 0.53 mV/W 400 mV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Power Resolution ± 0.5 %
Max. Average Power
10S: 10 W
20H: 20 W
70W: 70 W
10S: 10 W
Max. Average Power (1 min)
(cooling : minimum 3 min)
10S: 20 W
20H: 40 W
70W: 110 W
10S: 20 W
Max. Average Power Density b
1.064 µm, 10W CW
10.6 µm, 10W CW
36 kW/cm 2
11 kW/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 360 µs, 5 Hz
1.064 µm, 7 ns, 10 Hz
532 nm, 7 ns, 10 Hz
266 nm, 7 ns, 10 Hz
Max. Energy Density
5 J/cm 2
1.0 J/cm 2
0.6 J /cm 2
0.3 J /cm 2
Peak Power Density
14 kW/cm 2
143 MW/cm 2
86 MW/cm 2
43 MW/cm 2
Dimensions (mm)
10S: 38(H) x 38 (W) x 14 (D)
20H: 38(H) x 38 (W) x 45 (D)
70W: 38(H) x 38 (W) x 32 (D)
10S: 38(H) x 38 (W) x 36.6 (D)
Weight (head only)
10S: 0.13 kg
20H: 0.15 kg
70W: 0.19 kg
10S: 0.20 kg
Minimum Cooling Flow c 0.5 liter/min N. A.
Recommended Cooling Flow c 1.0 liter/min N. A.
Cooling Heat sink / water Stand alone
Recommended load Impedance 100 kΩ 10 MΩ
Output Impedance N. A. ≤ 50 Ω
Linearity vs beam dimension ± 0.7 %
PCB electrical supply N. A. + 12 V to + 16 V regulated
Max output signal N. A. 80 % of PCB electrical supply
