Gentec-EO UP and XLP12 - Manual (Page 29)

Version 5.0
Ultra Series UP Instruction Manual Gentec Electro-Optics Inc. All rights reserved
25
UP55G,
UP60G
- …-
H12
UP55M,
UP55G,
UP60M,
UP60G
- …-
HD
Typical sensitivity mV/J 0.013 0.008
Power sensitivity /
Energy sensitivity
J/W 4.62 4.46
Typical rise time in
calorimeter mode
ms 1800 1600
Minimum repetition
period
sec 14.3 12
Maximum pulse
width
ms 433 430
Maximum
measurable energy a
J 200 200
Noise equivalent
energy
mJ 250 250
Accuracy % ± 5 ± 5
a For 1,064 µm ; 360 µs pulses.
Higher pulse energy possible when customized for long pulse (ms), lower for short pulses (ns).
Specifications subject to change without notice.
