1.3 ULTRA SERIES UP, XLP SERIES SPECIFICATIONS
The following specifications are based on a one-year calibration cycle, an operating temperature of 15 to
28°C and a relative humidity not exceeding 80%. Storage 10 to 65°C and relative humidity not
exceeding 90%.
a Except 1350 – 1450 nm.
b The calibrations at 2.1 to 2.5 µm and 10.6 µm are on special request only.
c Nominal value, actual value depends on electrical noise in the measurement system.
d Without anticipation. ± 5 µW with anticipation.
e At 150 µW. 12 μW/°C for XLP12 with SOLO, 50 μW/°C for XLP12 with P-LINK.
Specifications subject to change without notice.
XLP12-
…-3S-H2
XLP12-3S-H2 XLPF12-3S-H2
Effective Aperture Diameter 12 mm
Spectral Range 0.19 µm – 20 µm 0.28 µm – 2.1 µm
Calibrated spectral range 0.248 – 2.5 µm and 10.6 µm b 0.308 – 2.1 µm a
Power Noise Level c, d ± 0.5 µW
Thermal Drift e 12 µW/ o C 6 µW/ o C
Typical Rise time (0-95%) 27 s (2.5 s with anticipation)
Typical sensitivity 200 mV/W 180 mV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Power Resolution ± 0.5 %
Max. Average Power 3 W
Max. Average Power (1 min)
(cooling : minimum 3 min)
3 W
Max. Average Power Density
1.064 µm, 1 W CW
1 kW/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 360 µs, 5 Hz
1.064 µm, 7 ns, 10 Hz
532 nm, 7 ns, 10 Hz
266 nm, 7 ns, 10 Hz
Max. Energy Density
5 J/cm 2
1 J/cm 2
0.6 J /cm 2
0.3 J /cm 2
Peak Power Density
14 kW/cm 2
143 MW/cm 2
86 MW/cm 2
43 MW/cm 2
Dimensions (H x W x D, in mm)
With isol. tube:
73 x 73 x 72
W/o isol. tube:
73 x 73 x 20
With isol. tube:
73 x 73 x 80
W/o isol. tube:
73 x 73 x 28
Weight
(head only, with isolation tube)
0.312 kg 0.324 kg
Cooling Heat sink
Recommended load Impedance 100 kΩ
Output Impedance N. A.
Linearity vs beam dimension ± 0.7 %
PCB electrical supply N. A.
Max output signal N. A.
