Gentec-EO UP and XLP12 - Manual (Page 27)

Version 5.0
Ultra Series UP Instruction Manual Gentec Electro-Optics Inc. All rights reserved
23
0
100
200
300
400
500
600
700
0 2 4 6 8 10 12
P
ow
er
[W]
Beam diameter [mm]
The absorber will be damaged if it is
used in this zone
Safe zone
(If the applied power does not
exceed the maximum power in
the specification)
FIG. 1-10 MINIMUM BEAM SIZES FOR UP WITH H-TYPE ABSORBER AT 1.064 µM.
