Version 5.0

Ultra Series UP Instruction Manual

Gentec Electro-Optics Inc. All rights reserved

8



a

Except 1350

– 1450 nm.

b

The calibrations at 2.1 to 2.5 µm and 10.6 µm are on special request only.

c

Nominal value, actual value depends on electrical noise in the measurement system.

d

Without anticipation. ± 5 µW with anticipation.

e

At 150 µW. 12

μW/°C for XLP12 with SOLO, 50 μW/°C for XLP12 with P-LINK.

Specifications subject to change without notice.
























…12-…-3S-VP

XLP12-3S-VP

Effective Aperture Diameter

12 mm

Spectral Range

0.248

– 20 µm

Calibrated spectral range

0.248

– 2.5 µm

b

Power Noise Level

c, d

± 0.5 µW

Thermal Drift

e

12 µW/

o

C

Typical Rise time (0-95%)

30 s (3.0 s with anticipation)

Typical sensitivity

220 mV/W

Calibration Uncertainty

± 2.5 % @ 1.064µm

± 3.5 % @ 0.25-2.5µm

Linearity with Power

± 2 %

Repeatability (Precision)

± 0.5 %

Power Resolution

± 0.5 %

Max. Average Power

3 W

Max. Average Power (1 min)

(cooling : minimum 3 min)

3 W

Minimum Repetition Rate

7 Hz with Antipation

1 Hz without Anticipation

Max. Average Power Density

1 W CW

30 W/cm2 @1.064

μm

8 W/cm2 @0.532

μm

4 W/cm2 @0.355

μm

Pulsed Laser Damage Thresholds

1.064 µm, 7 ns, 10 Hz

532 nm, 7 ns, 10 Hz
355 nm, 7 ns, 10 Hz

Max. Energy Density

4 J/cm

2

3 J /cm

2

1 J /cm

2

Dimensions (H x W x D, in mm)

With isol. tube:

73 x 73 x 72

W/o isol. tube:

73 x 73 x 20

Weight

(head only, with isolation tube)

0.316 kg

Cooling

Heat sink

Recommended load Impedance

100 kΩ

Output Impedance

N. A.

Linearity vs beam dimension

± 0.7 %

PCB electrical supply

N. A.

Max output signal

N. A.
