UP50N(M)-
…-W9-
...
UP50N-40S / 50H -W9
UP50M-50W -W9
Without PCB
UP50N-40S / 50H -W9
UP50M-50W -W9
With PCB
Aperture Diameter 50 mm
Spectral Range 190 nm - 10 µm
Calibrated spectral range a 0.248 – 2.5 µm
Power Noise Level 5 mW 40S / 50H / 50W: 3 mW
Typical Rise Time (0 – 95 %) 16 s (3.5 s with anticipation) 16 s (3.5 s with anticipation)
Typical sensitivity 0.12 mV/W
40S: 150 mV/W
50H: 120 mV/W
50W: 120 mV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Power Resolution ± 0.5 %
Max. Average Power
40S: 40 W
50H: 50 W
50W: 50 W
Max. Average Power
(1 min.)
(cooling : minimum 3 min)
40S: 80 W
50H: 85 W
50W: 85 W
Max. Average Power Density
1.064µm, 10W CW
100 kW/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 150 µs, 5 Hz
1.064 µm, 7 ns, 10 Hz
532 nm, 7 ns, 10 Hz
248 nm , 26 ns, 10 Hz
Max. Energy Density
100 J/cm 2
1.1 J/cm 2
1.1 J /cm 2
0.7J /cm 2
Peak Power Density
667 kW/cm 2
157 MW/cm 2
157 MW/cm 2
27 MW/cm 2
Dimension (mm)
40S: 89(H) x 89(W) x 32(D)
50H: 89(H) x 89(W) x 106(D)
50W: 89(H) x 89(W) x 40(D)
Weight (head only)
40S: 0.62 kg
50H: 0.93 kg
50W: 0.81 kg
Minimum Cooling Flow b 1 liter/min
Cooling Heat sink / Fan / Water
Recommended load Impedance > 100 kΩ 10 MΩ
Output Impedance N. A. ≤ 50 Ω
Linearity vs beam dimension ± 0.5 %
PCB electrical supply N. A. +12 to +16 V regulated
Max outpul signal N. A. 80 % of PCB electrical supply
a The calibrations at 2.1 to 2.5 µm are on special request only.
b Water temperature ≤ 22°C, 1/8 NPT compression fittings for ¼ inch semi-rigid tube.
Specifications subject to change without notice.
