Gentec-EO UP and XLP12 - Manual (Page 24)

Version 5.0
Ultra Series UP Instruction Manual Gentec Electro-Optics Inc. All rights reserved
20
Specifications subject to change without notice.
UP55N(M)-
…-VR-…
UP55N-50S/100H/150F-VR
UP55M-200W-VR
Without PCB
UP55N-50S/100H/150F-VR
UP55M-200W-VR
With PCB
Aperture Diameter 55 mm
Spectral Range 300 nm – 2.5 µm
Calibrated spectral range a 0.30 – 2.5 µm
Power Noise Level 15 mW
Typical Rise Time (0 - 95 %)
4 s
50 s (without anticipation)
5 s (with anticipation)
Typical sensitivity 0.04 mV/W
50S : 120 mV/W
100 H : 60 mV/W
150 F : 40 mV/W
200 W : 30 mV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Power Resolution ± 0.5 %
Max. Average Power
50S : 50 W
100H : 100 W
150F : 150 W
200W : 200 W
Max. Average Power
(1 min.)
(cooling : minimum 3 min)
50S : 50 W
100H : 100 W
150F : 150 W
200W : 200 W
Max. Average Power Density b
1.064 µm, 10 W CW 700 W/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 7 ns, 10 Hz
532 nm, 7 ns, 10 Hz
266 nm, 7 ns, 10 Hz
1.064 µm, 360 µs, 5 Hz
Max. Energy Density
6 J/cm 2
4 J/cm 2
1 J/cm 2
40 J/cm 2
Peak Power Density
860 MW/cm 2
570 MW/cm 2
143 MW/cm 2
111 kW/cm 2
Dimension (mm)
50S : 89(H) x 89(W) x 32(D)
100H : 89(H) x 89(W) x 106(D)
150F : 89(H) x 89(W) x 116(D)
200W : 89(H) x 89(W) x 44(D)
Weight (head only)
50S : 0.62 Kg
100H : 0.93 Kg
150F : 1.41 Kg
200W : 0.84 Kg
Minimum Cooling Flow c 1 liter/min
Cooling Heat sink / Fan / Water
Recommended load Impedance > 1 00 kΩ 10 MΩ
Output Impedance N. A. ≤ 50 Ω
Linearity vs beam dimension ± 0.5 %
PCB electrical supply N. A. +12 V to +16 V regulated
Max outpul signal N. A. 80 % of PCB electrical supply
a The calibrations at 2.1 to 2.5 µm are on special request only.
b See graph at the end of this section.
c Water temperature ≤ 22°C, 1/8 NPT compression fittings for ¼ inch semi-rigid tube.
