Version 5.0
Ultra Series UP Instruction Manual Gentec Electro-Optics Inc. All rights reserved
21
UP55C-2.5KW-HD
UP55C-2.5KW-HD
Without PCB
Effective Aperture Diameter 55 mm
Spectral Range 0.19 µm - 20 µm
Calibrated spectral range a 0.248 – 2.5 µm and 10.6 µm
Power Noise Level ± 0.2 W
Typical Rise time (0 - 95 %) 3.5 s (25 s without anticipation)
Typical sensitivity 8 µV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Max. Average Power 2500 W
Max. Average Power Density
1.064 µm, 500W CW
1.064 µm, 1500W CW
1.064 µm, 2500W CW
9.0 kW/cm 2
7.0 kW/cm 2
6.0 kW/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 7 ns, 10 Hz
532 µm, 7 ns, 10 Hz
Max. Energy Density
1.0 J/cm 2
0.6 J/cm 2
Peak Power Density
143 MW/cm 2
86 MW/cm 2
Dimension (mm) 116(H) x 116(W) x 48(D)
Weight (head only) 1.95 kg
Cooling Water
Recommended Cooling Flow b 3-4 liter/min
Recommended load Impedance 100 kΩ
Output Impedance N. A.
Linearity vs beam dimension ± 1 %
PCB electrical supply N. A.
Max outpul signal N. A.
a The calibrations at 2.1 to 2.5 µm and 10.6 µm are on special request only.
b Water temperature ≤ 22°C, 1/8 NPT compression fittings for ¼ inch semi-rigid tube.
Specifications subject to change without notice.
