Version 5.0
Ultra Series UP Instruction Manual Gentec Electro-Optics Inc. All rights reserved
16
UP25N(M)-
…-Hx-
…
UP25N-40S / 100H -H9
UP25N-250F-H12
UP25M-350W-H12
Without PCB
UP25N-40S / 100H -H9
UP25N-250F-H12
UP25M-350W-H12
With PCB
Aperture Diameter 25 mm
Spectral Range 190 nm - 20 µm
Calibrated spectral range a 0.248 – 2.5 µm and 10.6 µm
Power Noise Level
H9: 3 mW
H12: 10 mW
40S / 100H: 1 mW
250F-H12: 10 mW
350W-H12: 10 mW
Typical Rise Time (0 – 95 %)
H9: 5 s (1.3 s with anticipation)
H12: 7.9 s (1.3 s with anticipation)
H9: 1.3 s (with anticipation)
H12: 2 s (with anticipation)
Typical sensitivity
H9: 0.23 mV/W
H12: 0.1 mV/W
40S-H9: 150 mV/W
100H-H9: 60 mV/W
250F-H12: 24 mV/W
350W-H12: 24 mV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Power Resolution ± 0.5 %
Max. Average Power
40S: 40 W
100H: 100 W
250F: 250 W
350W: 350 W
Max. Average Power (1 min)
(cooling : minimum 3 min)
40S: 80 W
100H: 200 W
250F: 300 W
350W: 350 W
Max. Average Power Density b
1.064 µm, 10 W CW
10.6 µm, 10 W CW
45 kW/cm 2
14 kW/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 360 µs, 5 Hz
1.064 µm, 7 ns, 10 Hz
532 nm, 7 ns, 10 Hz
266 nm, 7 ns, 10 Hz
Max. Energy Density
9 J/cm 2
1.0 J/cm 2
0.6 J/cm 2
0.3 J/cm 2
Peak Power Density
25 kW/cm 2
143 MW/cm 2
86 MW/cm 2
43 MW/cm 2
Dimension (mm)
40S: 89(H) x 89(W) x 32(D)
100H: 89(H) x 89(W) x 106(D)
250F: 89(H) x 89(W) x 116(D)
350W: 89(H) x 89(W) x 40(D)
Weight (head only)
40S: 0.68 kg
100H: 0.99 kg
250F: 1.44 kg
350W: 0.87 kg
Minimum Cooling Flow c 1.5 liter/min
Cooling Heat sink / Fan / Water
Recommended Load Impedance > 100 kΩ 10 MΩ
Output Impedance N. A. ≤ 50 Ω
Linearity vs Beam Dimension ± 0.5 %
PCB Electrical Supply N. A. +12 V to +16 V regulated
Max Outpul Signal N. A. 80 % of PCB electrical supply
a The calibrations at 2.1 to 2.5 µm and 10.6 µm are on special request only
b See graph at the end of this section.
c Water temperature ≤ 22°C, 1/8 NPT compression fittings for ¼ inch semi-rigid tube.
Specifications subject to change without notice.
