1.4 UP CALORIMETER MODE SPECIFICATIONS
The UP Ultra Series has an optional mode that is called calorimeter mode. It allows you to measure
single shot pulse energy. This mode is accessible when you use a UP with a Gentec-EO monitor or
with your own data acquisition system. For more information, refer to
the monitor’s instruction
manual or call Customer Support at Gentec-EO, see p. ii, Contacting Gentec Electro-Optics Inc.
XLP(F)
-
…-
H2
UP12E
-
…-
H5
UP10K
-
…-
H5
UP17P
-
…-
H5
UP17P
-
…-
W5
UP19K
-
…-
H5
UP19K
-
…-
H9
UP19K
-
…-
VR
UP19K
-
…-
W5
Typical sensitivity
mV/J
25
F : 22.5
0.84
2.3
0.7
0.2
0.65
0.23
0.10
0.33
Power sensitivity /
Energy sensitivity
J/W
8
0.63
0.86
0.86
3
0.99
1
3.4
2
Typical rise time in
calorimeter mode
ms
1000
150
264
328
575
264
264
270
400
Minimum repetition
period
sec
16
1.5
4
4
5
4
4
4.5
5
Maximum pulse
width
ms
300
50
88
88
133
88
88
90
133
Maximum
measurable energy
a
J
5
5
3
15
200
15
25
40
200
Noise equivalent
energy
mJ
0.012
20
2
20
20
20
60
20
23
Accuracy
%
± 5
± 5
± 5
± 5
± 5%
± 5%
± 5%
± 5
± 5
UP25N,
-
…-
H9
UP25N,
UP25M
-
…-
H12
UP25T
-
…-
H12
UP50N,
UP50M
-
…-
W9
UP55N,
UP60N
-
…-
H9
UP55N
UP55M
-...-
VR
UP55N,
UP55M,
UP60N,
UP60M
-
…-
H12
Typical sensitivity
mV/J
0.14
0.05
0.05
0.020
0.028
0.010
0.015
Power sensitivity /
Energy sensitivity
J/W
1.67
2.19
2.19
5.28
4.25
4.25
4.46
Typical rise time in
calorimeter mode
ms
370
1300
1300
1400
1300
1300
1600
Minimum repetition
period
sec
4.6
11.5
11.5
11.1
11.1
11.1
12
Maximum pulse
width
ms
123
390
390
467
433
433
430
Maximum
measurable energy
a
J
40
40
40
500
200
500
200
Noise equivalent
energy
mJ
200
200
200
250
250
250
250
Accuracy
%
± 5
± 5
± 5%
± 5%
± 5%
± 5%
± 5
