Gentec-EO UP and XLP12 - Manual (Page 23)

Version 5.0
Ultra Series UP Instruction Manual Gentec Electro-Optics Inc. All rights reserved
19
UP55N(M)-
…-Hx-
…
UP60N(M)-
…-Hx-
…
UP55N-40S / 100H -H9
UP55N-300F -H12
UP55N-300DI -H12
UP55M-500W -H12
UP55M-700W -HD
Without PCB
UP55N-40S / 100H -H9
UP55N-300F -H12
UP55N-300DI -H12
UP55M-500W -H12
UP55M-700W -HD
With PCB
UP60N-40S / 100H -H9
UP60N-300F -H12
UP60N-300DI -H12
UP60M-500W -H12
UP60M-700W -HD
Without PCB
Aperture Diameter 55 mm 60 mm
Spectral Range 190 nm - 20 µm
Calibrated spectral range a 0.248 – 2.5 µm and 10.6 µm
Power Noise Level
H9: 5 mW
H12: 15 mW
HD: 45mW
H9: 2 mW
H12: 15 mW
HD: 45mW
H9: 5 mW
H12: 15 mW
HD: 45mW
Typical Rise Time (0 - 95 %)
H9: 11 s (2 s with anticipation)
H12: 18 s (2 s with anticipation)
HD: 14 s(2 s with anticipation)
H9: 2 s (with anticipation)
H12: 3 s (with anticipation)
HD: 5s (with anticipation)
H9: 11 s (2 s with anticipation)
H12: 18 s (2 s with anticipation)
HD: 14 s(2 s with anticipation)
Typical sensitivity
H9: 0.12 mV/W
H12: 0.06 mV/W
HD: 0.03mV/W
40S: 150 mV/W
100H: 60 mV/W
300F: 20 mV/W
300DI : 20mV/W
500W: 15 mV/W
700W: 8 mV/W
H9: 0.12 mV/W
H12: 0.06 mV/W
HD: 0.03mV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Power Resolution ± 0.5 %
Max. Average Power
40S: 40 W
100H: 100 W
300F: 300 W
300DI : 300W
500W: 500 W
700W: 700 W
Max. Average Power
(1 min.)
(cooling : minimum 3 min)
40S: 80 W
100H: 200 W
300F: 300 W
300DI : 300W
500W: 500 W
700W: 700 W
Max. Average Power Density b
1.064 µm, 10 W CW
10.6 µm, 10 W CW
45 kW/cm 2
14 kW/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 360 µs, 5 Hz
1.064 µm, 7 ns, 10 Hz
532 nm, 7 ns, 10 Hz
266 nm, 7 ns, 10 Hz
Max. Energy Density
9 J/cm 2
1.0 J/cm 2
0.6 J/cm 2
0.3 J/cm 2
Peak Power Density
25 kW/cm 2
143 MW/cm 2
86 MW/cm 2
43 MW/cm 2
Dimension (mm)
40S: 89(H) x 89(W) x 32(D)
100H: 89(H) x 89(W) x 106(D)
300F: 89(H) x 89(W) x 116(D)
300DI : 89(H) x 89(W) x 44(D)
500W: 89(H) x 89(W) x 40(D)
700W: 89(H) x 89(W) x 40(D)
Weight (head only)
40S: 0.62 kg
100H: 0.93 kg
300F: 1.41 kg
300DI :1.68 kg
500W: 0.81 kg
700W: 0.90 kg
Minimum Cooling Flow c 1.5 liter/min
Cooling Heat sink / Fan / Water
Recommended load Impedance > 100 kΩ 10 MΩ > 100 kΩ
Output Impedance N. A. ≤ 50 Ω N. A.
Linearity vs beam dimension ± 0.5 %
PCB electrical supply N. A. +12 V to +16 V regulated N. A.
Max outpul signal N. A.
80 % of PCB electrical
supply
N. A.
a The calibrations at 2.1 to 2.5 µm and 10.6 µm are on special request only.
b See graph at the end of this section.
c Water temperature ≤ 22°C, 1/8 NPT compression fittings for ¼ inch semi-rigid tube. For the stainless steel water module, the minimum
cooling flow is 1.0 liter/min for power higher than 90 W.
