UP19K-
…-VR-… UP19K-15S / 30H -VR
Without PCB
Effective Aperture Diameter 18 mm
Spectral Range 0.266 - 2.5 µm
Calibrated spectral range a 0.30 – 2.5 µm
Power Noise Level 2 mW
Typical Rise time (0 - 95 %) 36 s (2.5 s with anticipation)
Typical sensitivity 0.34 mV/W
Calibration Uncertainty ± 2.5 %
Linearity with Power ± 2 %
Repeatability (Precision) ± 0.5 %
Power Resolution ± 0.5 %
Max. Average Power
15S: 15 W
30H: 30 W
Max. Average Power (1 min.)
(cooling : minimum 3 min)
15S: 20 W
30H: 35 W
Max. Average Power Density
1.064µm, 10W CW
700 W/cm 2
Pulsed Laser Damage Thresholds
1.064 µm, 7 ns, 10 Hz
532 nm, 7 ns, 10 Hz
266 nm, 7 ns, 10 Hz
1.064 µm, 360 µs, 10 Hz
Max. Energy Density
6 J/cm 2
4 J /cm 2
1 J /cm 2
40 J/cm 2
Peak Power Density
860 MW/cm 2
570 MW/cm 2
143 MW/cm 2
111 kW/cm 2
Dimension (mm)
15S: 50(H) x 50(W) x 20.6(D)
30H: 50(H) x 50(W) x 56.3(D)
Weight (head only)
15S: 0.16 kg
30H: 0.21 kg
Cooling Heat sink
Recommended load Impedance 100 kΩ
Output Impedance N. A.
Linearity vs beam dimension ± 0.5 %
PCB electrical supply N. A.
Max outpul signal N. A.
a The calibrations at 2.1 to 2.5 µm are on special request only
Specifications subject to change without notice.
