Wire sawing system
6.% 7KH GLDPRQG ZLUH
SK-B_0008_e.mif page 43
12.4 Connecting the wire
Galvanically bound wire
The diameter of this wire does not change as
the result of wear.
For this reason when connecting wires with
varying degrees of wear, it is not necessary to
pay attention to the diameter.
Sintered wire
Varying diameters can occur as the result of
wear as the diameter changes.
For this reason attention must be paid to the
diameter when connecting wires with a varying
degree of wear.
Operating the pressing tongs
3UHVVLQJ OHYHU
5HVHW OHYHU
/LQN
3UHVVLQJ MDZ KROGHU
3UHVVLQJ LQVHUWV
Do not connect wires with different degrees
of wear: Maximum difference between the
two diameters: 0.2 mm max.
