Diamond Products SK-B - Manual (Page 3)

Wire sawing system
6.%
SK-B_0008_e.mif page 3
0.5 Table of contents
1 Safety instructions 4
1.1 Fundamentals 4
1.2 Inherent dangers of wire saws 6
1.3 Intended purpose 7
1.4 Before starting work 7
1.5 After work 8
2 Technical data 9
3 Working safely and efficiently 13
4 Design of the SK-B 14
5 Controls 15
6 Water 16
7 Modifying the drill stand 18
8 Range of applications 19
8.1 Connectable equipment 19
8.2 Possible uses for various jobs 20
9 Applications 21
9.1 Correct cutting direction 21
9.2 Incorrect cutting direction 21
9.3 Flush cuts on a wall 22
9.4 Correct wire positioning 23
9.5 Flush cutting on the right 23
9.6 Cutting flush with the ground 24
9.7 Bodenbündigschneiden / End of cut 25
9.8 Standard application l 26
9.9 Standard application ll 26
9.10 Smallest possible cut 26
10 Position and sequence of cuts 27
10.1 Planning the cuts 27
10.2 Sequence of cuts 28
10.3 Direct mounting with the
cutting template 29
10.4 Aligning the machine with the cutting
template 30
11 Connecting the SK-B 31
11.1 Connecting the main and feed circuits 31
11.2 Example power unit CR-S4 32
11.3 Example power unit CR-3 33
11.4 Example power unit BE-S2 34
12 The diamond wire 35
12.1 Diamond wire types 36
12.2 Preparing the ends of the wires 37
12.3 Avoiding non-circular wear 37
12.4 Connecting the wire 43
13 Inserting the wire, storing the wire 45
13.1 Insert the wire 45
13.2 Machine extended once 46
13.3 Pulling out the wire 46
13.4 Crossing the wire 47
13.5 Tensioning the wire, continuing work 47
14 Working with the SK-B 49
14.1 Wire cutting speed 49
14.2 Tensioning the wire / Starting 51
14.3 Switching on the power unit 51
14.4 Working 51
14.5 Interrupting the cut 52
14.6 Terminating work 52
15 Troubleshooting 53
16 Maintenance 56
16.1 Maintenance table 56
16.2 Replacing drive bindings 57
16.3 Repair 60
17 Transport, taking out of service,
storing, disposal
61
17.1 Transport 61
17.2 Taking out of service, storage 61
17.3 Disposal 61
18 Accessories, spare parts list 62
19 Table of contents spare part list 63
