Diamond Products SK-B - Manual (Page 30)

3RVLWLRQ DQG VHTXHQFH RI FXWV
Wire sawing system
6.%
page 30 SK-B_0008_e.mif
10.4 Aligning the machine with the
cutting template
The cutting template can be secured with the
screw of the mounting clamp for the deflection
pulley unit.
The drill stand can then be aligned in the
correct position.
With the mounted cutting template the
machine can be aligned in the correct position
in relation to the cutting line.
