Atlantis Land Compact Router ADSL A02-RA110 - Manual (Page 83)

COMPACT ROUTER ADSL
A02-RA110 Pag. 75
files before you can upload them.
Upload Click Upload to begin the upload process. This process may
take up to two minutes.
Reset Click this button to clear all user-entered configuration
information and return the ADSL Router to its factory
defaults. Refer to the Resetting the ADSL Router section.
After you see the Firmware Upload in Process screen, wait two minutes before
logging into the ADSL Router again.The ADSL Router automatically restarts in this
time causing a temporary network disconnect. In some operating systems, you
may see the following icon on your desktop.
After two minutes, log in again and check your new firmware version in the
System Status screen. If the upload was not successful, the following screen will
appear. Click Back to go back to the Firmware screen.
