COMPACT ROUTER ADSL
A02-RA110 Pag. 73
The following table describes the labels in this screen.
Label Description
Reset ADSL Line Click this button to reinitialize the ADSL line. The large text
box above then displays the progress and results of this
operation, for example:
"Start to reset ADSL
Loading ADSL modem F/W...
Reset ADSL Line Successfully!"
ATM Status Click this button to view ATM status.
ATM Loopback
Test Click this button to start the ATM loopback test. Make sure
you have configured at least one PVC with proper VPIs/VCIs
before you begin this test. The ADSL Router sends an OAM
F5 packet to the DSLAM/ATM switch and then returns it
(loops it back) to the ADSL Router.
The ATM loopback test is useful for troubleshooting
