COMPACT ROUTER ADSL
A02-RA110 Pag. 25
The following table describes the labels in this screen.
Label Description
Service Name Type the name of your PPPoE service here.
User Name
Configure User Name and Password fields for PPPoA and
PPPoE encapsulation only. Enter the user name exactly as your
ISP assigned. If assigned a name in the form user@domain
where domain identifies a service name, then enter both
components exactly as given.
Password Enter the password associated with the user name above.
IP Address A static IP address is a fixed IP that your ISP gives you. A
dynamic IP address is not fixed; the ISP assigns you a different
one each time you connect to the Internet. The Single User
Account feature can be used with either a dynamic or static IP
address.
Select Obtain an IP Address Automatically if you have a
dynamic IP address; otherwise select Static IP Address and type
your ISP assigned IP address in the IP Address text box below.
Connection Select Connect on Demand when you don't want the connection
up all the time and specify an idle time-out (in seconds) in the
Max. Idle Timeout field. The default setting selects Connection
on Demand with 0 as the idle time-out, which means the
Internet session will Select Nailed-Up Connection when you
want your connection up all the time. The ADSL Router will try to
bring up the connection automatically if it is disconnected.
Network
Address
Translation Select None, SUA Only or Full Feature from the drop-sown list
box. Refer to the NAT chapter for more details.
Back Click Back to go back to the first wizard screen.
Next Click Next to continue to the next wizard screen.
4.10.2 RFC 1483
Select RFC 1483 from the Encapsulation drop-down list box in the first wizard
screen to display the screen as shown.
This configuration is valid in case of a subscription with a static IP and active NAT
(SUA) (for the managing of the public class turn to the CD handbook). Make sure
that the parameters are, in case of RFC1483, the ones in the picture, if not
specifically shown by the ISP.
