COMPACT ROUTER ADSL

A02-RA110 Pag. 16

Step 4. You should now see the Site Map screen.

3.6 Navigating the Compact Router ADSL Web
Configurator

The following summarizes how to navigate the web configurator from the Site
Map screen. Screens vary slightly for different ADSL Router models.
Select a language from the Language drop-down list box.

Click Wizard Setup to begin a series of screens to configure the ADSL Router
for the first time.

Click a link under Advanced Setup to configure advanced ADSL Router
features.

Click a link under Maintenance to see the ADSL Router performance
statistics, upload firmware and back up, restore or upload a configuration file.

Click SITE MAP to go to the Site Map screen.

Click Logout in the navigation panel when you have finished a ADSL Router
management session.
