COMPACT ROUTER ADSL
A02-RA110 Pag. 71
clients using the DHCP server.
The following table describes the labels in this screen.
Label Description
Host Name This is the name of the host computer.
IP Address This field displays the IP address relative to the Host Name
field.
MAC Address This field displays the MAC (Media Access Control) address
of the computer with the displayed host name.
Every Ethernet device has a unique MAC address. The
MAC address is assigned at the factory and consists of six
pairs of hexadecimal characters, for example,
00:AA:BB:00:00:02.
12.4 Diagnostic Screens
These read-only screens display information to help you identify problems with
the ADSL Router. Click Diagnostic to display the following screen.
12.4.1 Diagnostic General Screen
Click Diagnostic and then General to open the screen shown next.
