COMPACT ROUTER ADSL
A02-RA110 Pag. 72
The following table describes the labels in this screen.
Label Description
TCP/IP Address Type the IP address of a computer that you want to ping in
order to test a connection.
Ping Click this button to ping the IP address that you entered.
Reset System Click this button to reboot the ADSL Router. A warning dialog
box is then displayed asking you if you're sure you want to
reboot the system. Click OK to proceed.
Back Click this button to go back to the main Diagnostic screen.
12.4.2 Diagnostic DSL Line Screen
Click Diagnostic and then DSL Line to open the screen shown next.
