COMPACT ROUTER ADSL
A02-RA110 Pag. 9
CHAPTER 3: Introducing the Web Configurator
This chapter describes how to access and navigate the web configurator.
3.1 Web Configurator Overview
The embedded web configurator allows you to manage the Compact Router
ADSL from anywhere through a browser such as Microsoft Internet Explorer or
Netscape Navigator. Use Internet Explorer 6.0 and later or Netscape Navigator
7.0 and later versions with JavaScript enabled. It is recommended that you set
your screen resolution to 1024 by 768 pixels.
This section describes the configuration required by LAN-attached PCs that
communicate with the Compact Router ADSL, either to configure the device or for
network access. These PCs must have an Ethernet interface installed properly, be
connected to the ADSL Router either directly or through an external Switch, and
have TCP/IP installed and configured to obtain an IP address through a DHCP
server or a fixed IP address that must be in the same subnet of the Compact
Router ADSL. The default IP address of the Compact Router ADSL is
192.168.1.254 and subnet mask is 255.255.255.0. The best and easy way is to
configure the PC to get an IP address from the ADSL Router. Also make sure you
have UNINSTALLED any kind of software firewall that can cause problems while
accessing the 192.168.1.254 IP address of the router.
Please follow the steps below for PC’s network environment installation. First of
all, please check your PC’s network components. The TCP/IP protocol stack and
Ethernet network adapter must be installed. If not, please refer to MS Windows
related manuals.
Any TCP/IP capable workstation can be used to communicate
with or through the Compact Router ADSL. To configure other
types of workstations, please consult the manufacturer’s
documentation.
