COMPACT ROUTER ADSL
A02-RA110 Pag. 29
The following table describes the labels in this screen.
Label Description
User Name Enter the user name exactly as your ISP assigned. If assigned
a name in the form user@domain where domain identifies a
service name, then enter both components exactly as given.
Password Enter the password associated with the user name above.
IP Address This option is available if you select Routing in the Mode field.
A static IP address is a fixed IP that your ISP gives you. A
dynamic IP address is not fixed; the ISP assigns you a
different one each time you connect to the Internet. The Single
User Account feature can be used with either a dynamic or
static IP address. Click Obtain an IP Address Automatically if
you have a dynamic IP address; otherwise click Static IP
