COMPACT ROUTER ADSL
A02-RA110 Pag. 54
and the end port number in the End Port No. field.
End Port No. Enter a port number in this field.
To forward only one port, enter the port number again in the
Start Port No. field above and then enter it again in this field.
To forward a series of ports, enter the last port number in a
series that begins with the port number in the Start Port No.
field above.
IP Address Enter your server IP address in this field.
Save Click Save to save your changes back to the ADSL Router.
Cancel Click Cancel to return to the previous configuration.
7.6 Configuring Address Mapping
Ordering your rules is important because the ADSL Router applies the rules in the
order that you specify. When a rule matches the current packet, the ADSL Router
takes the corresponding action and the remaining rules are ignored. If there are
any empty rules before your new configured rule, your configured rule will be
pushed up by that number of empty rules. For example, if you have already
configured rules 1 to 6 in your current set and now you configure rule number 9.
In the set summary screen, the new rule will be rule 7, not 9. Now if you delete
rule 4, rules 5 to 7 will be pushed up by 1 rule, so old rules 5, 6 and 7 become
new rules 4, 5 and 6.
To change the ADSL Router’s address mapping settings, click NAT, Select Full
Feature and click Edit Details to open the following screen.
