CHAPTER 5: LAN Setup
This chapter describes how to configure LAN settings.
5.1 LAN Overview
A Local Area Network (LAN) is a shared communication system to which many
computers are attached. A LAN is a computer network limited to the immediate
area, usually the same building or floor of a building.
The LAN screens can help you configure a LAN DHCP server and manage IP
addresses.
5.1.1 LANs, WANs and the ADSL Router
The actual physical connection determines whether the ADSL Router ports are
LAN or WAN ports. There are two separate IP networks, one inside, the LAN
network; the other outside: the WAN network as shown next:
