COMPACT ROUTER ADSL
A02-RA110 Pag. 68
The following table describes the labels in this screen.
Label Description
System Status
System Name This is the name of the ADSL Router. It is for identification
purposes.
RAS F/W Version This is the firmware version and the date created.
DSL FW Version
This is the DSL firmware version associated with the ADSL
Router.
Standard This is the standard that the ADSL Router is using.
WAN Information
IP Address
This is the WAN port IP address.
IP Subnet Mask This is the WAN port IP subnet mask.
Default Gateway This is the IP address of the default gateway, if applicable.
VPI/VCI
This is the Virtual Path Identifier and Virtual Channel
Identifier that you entered in the first Wizard screen.
LAN Information
MAC Address
This is the MAC (Media Access Control) or Ethernet address
unique to the ADSL Router.
IP Address This is the LAN port IP address.
IP Subnet Mask This is the LAN port IP subnet mask.
DHCP This is the WAN port DHCP role - Server, Relay (not all
ADSL Router models) or None.
DHCP Start IP This is the first of the contiguous addresses in the IP
address pool.
DHCP Pool Size This is the number of IP addresses in the IP address pool.
Show Statistics Click Show Statistics to see router performance statistics
such as number of
packets sent and number of packets received for each port.
