Parts list auto pro gun assembly cpd-4000-a – Magnum Venus Plastech CB-5000-PRX RTM Control Box User Manual
Page 35
35
1
58704-1
1
MOUNTING PAD - PRO GUN
PARTS LIST
Auto Pro Gun Assembly CPD-4000-A
PART NO.
ITEM
QTY
DESCRIPTION
1.75
4-1/4
2-1/2
4x 1/4-20 UNC
(PARTIAL BOTTOM VIEW)
2.55
MOUNTING HOLES
2
CPC-1200-A
1
ACTUATOR ASSEMBLY
3
DUO-4100-A
1
GUN BLOCK ASSEMBLY
5
F-HB-04C-08
1
HEX BOLT
4
F-SW-04
1
LOCK WASHER
6
02806-2
2
PAN HEAD SCREW
7.80
7
01443
2 FT.
2 - 1 FT. TUBE SECTIONS
8
06946
1
Y CONNECTOR
