Magnum Venus Plastech CB-5000-PRX RTM Control Box User Manual
Page 11
11
VACCUM VALVE FLUSH ASSY.
AIR/FLUSH FOR VACUUM ASSIST VALVE
VACUUM ASSIST LINE
Inner/Part Seal
Outer Mold Seal
RTM-LT-CK
TO WASTE TANK/BUCKET
MAS-1000
Mold Half
MAS-1001
VACCUM VALVE - OFF SIGNAL (#3)
VACCUME VALVE - ON SIGNAL (#4)
Vacuum
Cl
a
m
p
RTM-3000
Auto Pro Gun
RTM VALVE - ON SIGNAL (#7)
RTM VALVE - OFF SIGNAL (#8)
MAS-1000
TO WASTE TANK / BUCKET
MAS-1001
Auto Pro Gun
Gun “ON” Signal (#9)
Gun “OFF” Signal (#10)
RTM Flush Assembly
Use caution to connect the correct signal
line to the corresponding purge material
