31
1 58704-1 1 MOUNTING PAD - PRO GUN
PARTS LIST
Auto Pro Gun Assembly CPC-2000-A
PART NO. ITEM QTY DESCRIPTION
4-1/4
2-1/
2
4x 1/4-20 UNC
(PARTIAL BOTTOM VIEW)
2.55
MOUNTING HOLES
2 CPC-1200-A 1 ACTUATOR ASSEMBLY
3 VFTC-4100-A 1 GUN BLOCK ASSEMBLY
5 F-HB-04C-08 1 HEX BOLT
4 F-SW-04 1 LOCK WASHER
8 VFIT-6025 1 FIT NOZZLE
9 8704-4-1 1 NOZZLE CAP
6 VPG-1003 1 STATIC MIXER
7 VPG-1002 1 DIFFUSER
8.69
1.7
5
10 02806-2 2 PAN HEAD SCREW
3A VFTC-4100-F-A 1 ABRASIVE GUN BLOCK
QTY
OPTIONAL PARTS AND ASSEMBLIES
ITEM PART NO. DESCRIPTION
