Magnum Venus Plastech CB-5000-PRX RTM Control Box - Manual (Page 21)

21
25
INCL WITH VALVE 1 LOCK WASHER
24 INCL WITH VALVE 1 NUT
23 09524 1 PULSE VALVE
22 08801 27 1/16 barb to 10-32 connector
21 F-KN-832 4 KEP NUT
20 F-PH-832-06 2 PAN HEAD SCREW
19 09068 2 ANGEL MNT BRKT - MINI VALVE
18 CB-5003-PRX 1
17 07414 2 WATTS REGULATOR
16 F-HB-04C-08 4 1/4 HEX BOLT
15 CB-5003-PRX-11 2 MOUNTING BRACKET
14 9807-1-1 5 PILOT OPERATOR
13 9807-2-1 1 PRESSURE SWITCH
12 F-HN-632 4 NIPPLE
11 F-PH-632-06 6 PAN HEAD SCREW
10 F- STS-632-06 12 SELF TAPPING SCREW
9 07641 1 MULTI SOCKET
8 F-HN-04C 8 PLATED HEX NUT
7 9811-1-1 1 PRE SET COUNTER
6 07311 1 PUSH BUTTON
5 05804 2 PNL MNT GAUGE
4 CB-5002-PRX 1 CONTROL PANEL FACE
3 CB-5005-PRX 2 ANGLE BRACKET
2 CB-5001B-PRX 1 PRIMAX CONTROL BOX
1 CB-5001A-PRX 1 PRIMAX CONTORL BOX FRONT
PARTS LIST
ITEM PART NUMBER QTY DESCRIPTION
MAGNUM VENUS PLASTECH
PRX CONTROL BOX ASSY CB-5000-PRX
