Optional parts and assemblies, Figure 1-1 – Magnum Venus Plastech CB-5000-PRX RTM Control Box User Manual
Page 25
25
24
00373
2
POLY NUT
OPTIONAL PARTS AND ASSEMBLIES
PART NO.
ITEM
DESCRIPTION
QTY
FIGURE 1-1
1
58757-1
1
MOUNTING PAD - PRO GUN
PARTS LIST
SuperPro Automatic Gun Assembly SPG-1000-A
PART NO.
ITEM
QTY
DESCRIPTION
2
5110-6-1
1
GASKET - 2 POSITION GUN
3
VFTC-4200
1
ACTUATOR ASSEMBLY
4
5104-00-01
1
GUN BLOCK ASSEMBLY
5
5107-27-3
1
STD TURBULENT MIXER
6
T-002552C
1
SPRAY NOZZLE .052 x 50
7
8704-4-1
1
NOZZLE CAP
8
58681-1
1
AUTO FLUSH VALVE BODY
9
58716-1
1
PUSH STEM
10
58717-1
1
MANUAL / AUTO FLUSH BODY
11
58718-1
1
BACK UP RING
12
00973
1
GRIP RING
13
01019
1
O-RING
14
04356
1
SPRING
15
7304-3-1
1
NYLON SEAL
16
7701-6-3
1
BARBED FITTING
17
7701-2-1
1
HOSE CLAMP
18
7202-4-8
1
LOCK WASHER
19
7101-1-4
1
HEX CAP SCREW
20
MPH-2534
1
MALE ELBOW POLY FITTING
25
00437
2
FERRULE
21
7701-6-14
1
STRAIGHT POLY FITTING
22
00667
1
COMPACT ELBOW
23
02806-2
4
SLOTTED PAN HEAD SCREW
M6707-1-1
1
MANUAL - SUPERPRO GUNS
