Prx control box assy cb-5000-prx, Magnum venus plastech – Magnum Venus Plastech CB-5000-PRX RTM Control Box User Manual
Page 20
20
66
09169-1
5
3-WAY PNL MNT VALVE
65
F-BHCS-04C-08
4
Hex Socket Button Head Cap Screw
64
09613
1
CORD SET
63
BV-6F6F-LP
1
BALL VALVE
62
PF-ME-06
1
ELBOW
61
NOF-06
1
FILTER
60
PF-SE-04-BR
1
MALE ELBOW
59
F-HN-06C
4
HEX NUT
58
F-SW-06
4
LOCK WASHER
57
F-HB-06C-40
4
HEX CAP SCREW
56
COL-CLMP
2
COLUMN CLAMP
55
PF-HN-06-04
1
HEX NIPPLE
54
07645
10
TERMINAL PLUG - 1/4 TUBE
53
07640
1
MULTI-PLUG
52
07644
10
TERMINAL SOCKET - 1/4 TUBE
51
01659
2
CHECK VALVE
50
TRU-1021
2
SWIVEL ELBOW FITTNING
49
07225
1
MALE CONNECTOR
48
00446-1
1
.25 TEE
47
PF-HN-04
1
HEX NIPPLE
46
F-KN-440
2
KEP NUT
45
F-PH-440-10
2
PAN HEAD SCREW
44
07254
1
SOLINOID VALVE
43
09575
2
STRAIN RELIEF
42
7701-3-19
2
BULKHEAD FITTING
41
7701-6-3
4
10-32 BARBED FITTING
40
MPM-2585
2
MALE ELBOW
39
PF-AP-04
2
ALLEN PLUG
38
00416
1
BRANCH TEE
37
09852
2
4-WAY TOGGLE VALVE
36
07234
3
MALE POLY ELBOW
35
PF-RB-04-02
1
PIPE BUSHING
34
08804
2
ELBOW
33
08185
2
FITTING
32
F-PH-832-20
2
PAN HEAD SCREW
31
7701-6-7
15
BARB FITTING
30
F-FW-03
2
29
08807
10
SWIVEL TEE
28
09750
3
SHUTTLE VALVE
27
09187
2
4-WAY VALVE - DUAL PILOT
26
F-HN-832
4
HEX NUT
PARTS LIST
ITEM
PART NUMBER
QTY
DESCRIPTION
MAGNUM VENUS PLASTECH
PRX CONTROL BOX ASSY CB-5000-PRX
