Chapter, Component drawings – Magnum Venus Plastech CB-5000-PRX RTM Control Box User Manual
Page 17
17
CHAPTER
Component Drawings:
1. CB-5000-PRX
RTM CONTROL BOX
2. RTMFLUSH
RTM DUAL FLUSH ASSEMBLY
3. SPG-1000-A
AUTOMATIC SUPER PRO GUN ASSEMBLY
4. CPC-1000-A
AUTOMATIC CLASSIC PRO GUN
5. CPC-2000-A
AUTOMATIC CLASSIC PRO GUN
– FIT MIX CHAMBER
6. Electrical Diagram
7. CSD-1000-UPS SENSOR ASSEMBLY
– UPS
8. CSD-1006
PUMP BASE PLATE MODIFICATION
9. CSD-1000-HV
SENSOR ASSEMBLY
– HV UPS
10.
PNEUMATIC CIRCUT
6
