Liquid Controls HML110 IOM User Manual
Page 4
HML 110
4
110_EN_LC_5_3_6X.doc
ELECTRIC CHARACTERISTICS
Classification of the converter: class I, IP 65, category of installation II
Power supply
versions
Power supply
voltage
Power supply
frequency
Pmax
current
max
HV
90-265 Vac
44 - 66 Hz
3W/5VA
35 mA
LV
12-60 Vdc
18-45 Vac
0 - 44 - 66 Hz
3W/5VA
300 mA
The converter can be installed internally or externally with in the following specification
Altitude: from –200 to 6000 m (from -656 to 19685 feet)
Humidity range: 0 - 98%
Line voltage range: (see table of Electrical Characteristics above)
TECHNICAL CHARACTERISTICS
INPUT/OUTPUT ISOLATION
ENVIRONMENTAL CONDITIONS OF USE
OPERATING TEMPERATURE
CONVERTER
Ambient Temp.
Min. Max
°C °F °C
°F
-10* -14* 50 122
Input/output insulated up to 500V
The output 4-20 mA and output 24 Vdc are electrically connected
* In situations of discontinuous use in cold ambient temperatures, the
installation of an additional heat source may be necessary.
