6
DB Manager
fleetConnect system Components
fleeTConneCT offICe
The FleetConnect Office contains four executable
programs FCRead.exe, FCEdit.exe, FCLoad.exe and an
installation program for the USB button reader.
FCEdit is a graphical user interface for office computers
where users can manage operational data, validate any
changes made in the field (for example adding a new
customer), configure print tickets, and change system
settings. FCEdit also plays a large role in the setup of a
FleetConnect System by helping map RFID buttons and
populating the FleetConnect database. The USB button
reader plugs into any office computer USB port and
reads the ID number of the RFID buttons for FCEdit to
map the RFID buttons.
FCRead converts transaction files, created by DMS
i1000s in the field, into ASCII text files for use in FCEdit
and third party software.
db ManaGer
DB Manager is used to setup and manage wireless
communication between DMS i1000s in the trucks and
personal computers in your office. DB Manager contains
two programs LCPSetup.exe and DBManager.exe. The
first program, LCPSetup.exe, aligns communication
parameters and conducts testing to confirm wireless
communication between the office PC and the DMS
i1000. The second, DBManager.exe, specifies the DMS
i1000s in the field, sets the file paths to the office PC,
sets a schedule to check for modified FleetConnect
database files and sends those files to the DMS i1000s
in the field.
Cell ModeM
Cell modems enable long distance wireless data
transmissions between DMS i1000s in the field and
office PCs. Cell modems and service contracts are
purchased separately from a cellular service provider.
rf TransCeIvers
The RF transceivers are designed for short, line-of-sight
wireless transmissions between DMS i1000s in the field
and the office PC. .
usb flash MeMory devICe
The USB Flash Memory Device is a data repository used
to transfer data between the DMS i1000 Module and the
office PC. A USB Flash Memory Device is included with
the purchase of a DMS i1000.
Cell Modem
USB Flash Memory Device
FleetConnect Office
USB Button Reader
RF Transceivers
InTroduCTIon
