PosT InsTallaTIon—bIll of MaTerIals
08198
Hex Bushing ¾-½" NPT (2)
07223
Plug ½-40 NPT (7)
84065
Enclosure Cover Assembly
06635
Flat Washer .265" ID
08193
Captive Screw ¼-20 x
⅝"
08133
Screw #8-32 x
⅜" (4)
70471
Selector Switch Knob
84048
LCR 600 Switch Plate
Weights & Measures seals
To detect possible intrusions into Weights & Measures approved calibrations on a LectroCount LCR 600, fillister holes
have been drilled into the switchplate screw and the latch. To seal according to Weights & Measures standards, a wire
is threaded through the fillister holes and closed with a lead seal.
sWITChPlaTe
laTCh
bill of Materials—external Components
