Impulse 463E User Manual
Page 66
© Sealevel Systems, Inc.
- 63 -
SeaI/O User Manual
(0x65) Get the A/D, D/A Configuration
Before setting the configuration, it is often useful to retrieve the current configuration
of the SeaI/O module. Modbus command 0x65 will retrieve the settings currently in
use, so that they may be altered and set via command 0x64.
Request
Response
Field Name (Hex)
Field Name
(Hex)
Function
65
Function
65
Device Config
00
Channels 1-4 Config
00
Channels 5-8 Config
00
Channels 9-12 Config
00
Channels 13-16 Config
00
The actual values for the configuration are enumerated in SeaMaxW32.h, included
with the SeaMAX libraries. Upon a successful operation, the SeaI/O module will
respond with the response packet containing the current module configuration.
