SeaI/O-463 Optional Items
Depending upon your application, you are likely to find one or more of the following
items useful for interfacing the SeaI/O-463 to real-world signals. All items can be
4343.
For TTL applications:
Terminal Block Kit - (Item# KT107)
−
Kit includes the TB07 screw terminal block and CA167 ribbon cable for
connecting one of the SeaI/O-463’s 50-pin header connectors to your I/O.
6” Snap track and DIN rail clips are included for DIN rail mounting.
IDC 50 to IDC 50 Pin 40" Ribbon Cable (Item# CA167)
−
Interfaces each of the SeaI/O-463’s 50-pin header connectors.
Simulation/debug module (Item# TA01)
−
Module allows monitoring status of output pins and controlling state of
input pins. An LED corresponding to each port bit illuminates to indicate
state. Eight position DIP-switches are used to generate input status
changes.
