The user message is displayed on the top four lines of the 1837 display. This message can be a maximum
of 80 characters (spaces count as a character)
and is entered into the system memory in four blocks.
The example below shows how the sample message was divided into four blocks and centered on the
screen.
Use the blank table to organize your own message. Only upper case letters, numbers and spaces
can be programmed from the system keypad.

Factory Default User Message = This Space is For YOUR Centered User Programmable Message.

After organizing the user message in the table above, follow the instructions below to enter the message into the system. After
each desired letter, number or space is displayed on the directory, remember to press

*

to enter that character. Spaces count as

a character and must be entered into memory as a character. After a complete block of characters (including spaces) has been
entered, press

*

to enter the block, then start the next block.

Note: The factory default message was programmed from a PC, therefore upper and lower case letters are displayed.

Example: WELCOME TO THE OAKWOOD CONDOMINIUMS PLEASE DRIVE CAREFULLY

Block 1

Block 2

Block 3

Block 4

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

W

E

L

C

O

M

E

T

O

T

H

E

O

A

K

W

O

O

D

C

O

N

D

O

M

I

N

I

U

M

S

P

L

E

A

S

E

D

R

I

V

E

Block 1

Block 2

Block 3

Block 4

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

C

A

R

E

F

U

L

L

Y

1. Press and enter your four-digit MASTER CODE (beep).

The LCD display on the 1837 system will read: BLOCK 1.

2. Enter the characters into block 1 (refer to 3.4.1 for reference). Remember to press (beep) after each character.

3. After the last character in the block has been entered, press (beep) to enter the entire block.

The LCD display will read: BLOCK 2.

4. Repeat steps 2 and 3 to enter characters into block 2.

The LCD display will read: BLOCK 3.

5. Repeat steps 2 and 3 to enter characters into block 3.

The LCD display will read: BLOCK 4.

6. Repeat steps 2 and 3 to enter characters into block 4.

7. Press (beep) to enter all four blocks into the system memory.

8. Press together to end this programming sequence (beeeeeep).

9. The new user message will be centered on the screen.

??

??

??

??

00

OPER

OPER

88

TUV

TUV

00

OPER

OPER

3.4.4 Programming the User Message – 1837 System
