1835-065-E-7-13 32
This programming sequence sets which relay(s) will activate when the system receives a rotary-dial 9 open command from a
residents rotary telephone. The system can be programmed so that only one relay will activate, or any combination of relays will
activate. TIP: The relay that you designate as the primary relay should be programmed to activate from a rotary 9 command.
1833, 1835 and 1837 have 3 relays, relay 0, relay 1 and relay 2. 1834 only has 2 relays, relay 1 and relay 2.
Factory setting = 010 (only relay 1 activates)
3.3.6 Rotary-Dial 9 Relay ( s ) Activation
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the three-digit (1's or 0's only) rotary 9 code, then press (beep).
Three-digit positions: 1st digit position - Relay 0, 2nd digit position - Relay 1, 3rd digit position - Relay 2.
To activate a relay - enter a 1 in a digit position.
To NOT activate a relay - enter a 0 in a digit position.
Example: entering 010 will cause only relay 1 to activate. Entering 101 will cause both relay 0 and relay 2 to activate.
Example for 1834 only: 1st digit position is always 0 because there is no Relay 0.
3. Press together to end this programming sequence (beeeeeep).
?? ?? ?? ??
11
SP SP
55
JKL JKL
00
OPER OPER
This programming sequence will set the telephone entry system to dial out in either a touch-tone or rotary format. Generally,
this will be set for touch-tone.
Factory setting = touch-tone.
3.3.5 Touch-Tone / Rotary-Dial
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) for touch-tone, OR (beep) for Rotary
3. Press together to end this programming sequence (beeeeeep).
?? ?? ?? ??
77
PQRS PQRS
00
OPER OPER
00
OPER OPER
11
SP SP
00
OPER OPER
