6300-065-Z-7-12 23
Main Terminal
#15 and #20
CLOSE Direction
Photo Sensor
Auxiliary Terminal #7 and #8
OPEN Direction Photo Sensor
(2) Two 115 VAC
Convenience Outlets
Entrapment Protection Device Note:
Specific gate installations may require more
entrapment protection devices than are shown
here. Install them where necessary to protect
against ANY potential entrapment or hazard area.
CLOSE Entrapment Sensor (Photo Sensor): Obstructed
closing-direction photo beam will REVERSE and OPEN the gate
during the closing-direction only. Note: If the auto-close timer
is ON, when gate reaches the open
position, timer will not close the gate.
Another input command is needed to
reset and close the gate.
OPEN Entrapment Sensor (Photo Sensor): Obstructed
opening-direction photo beam will STOP the gate during the
opening-direction only. Gate will resume the open cycle when
the obstructed photo beam has been cleared.
Closing-Direction Photo Beam
Opening-Direction
Photo Beam
Potential Entrapment
Zone Hazard Area
Potential Pinch Point
Hazard Area
Potential
Pinch Point
Hazard Area
Potential
Entrapment
Area
Potential
Hazard Area
Potential
Hazard Area
Opening Gate
Closing Gate
Wall
Wall
20
19
18
17
16
15
14
13
12
NC
NO
1 ON
2
3
4
5
6
7
8
1 ON
2
3
4
5
6
7
8
Secondary Entrapment Protection Device:
In addition to the inherent reversing sensor system, the Model 6300 has terminal connections for photo sensors-Type B1
secondary entrapment protection device required by UL 325 standards. Entrapment protection devices must be installed to
reduce the risk of injury. Install these devices where the risk of entrapment or a hazard exists while the gate is moving. Specific
installations will vary.
SECTION 4 - ENTRAPMENT AND SAFETY PROTECTION
4.1 Main and Auxiliary Terminals Description
A
A
B
SW 2
1 ON
2
3
4
5
6
7
8
Common
4
5
6
7
8
Standard Reverse
(Normally Open)
B
#7 Normally Open #
8
Common
SW 2, switch 5
MUST be OFF.
