1601-065-L-3-13 29
6.3 DIP-Switch Settings
6.2 DC System Description
Switch Function Setting Description
Operation
Changes
Open Direction
Automatic
Power-up
Activation
OFF
ON
ON
OFF
OFF
OFF
OFF
Operator Type
Not Used
Not Used
Not Used
Do Not Adjust Do Not Adjust Timer Not Used Charging LED
Orange
Yellow
Not Used
Not Used
1
2
3
4
5
6
7
8
Arm will automatically open when a power outage occurs.
Set so that the arm runs to the open (up) direction upon loss of AC power.
OFF
ON
OFF
When AC power is restored, an input (push button, loop, radio receiver, etc.) is
required to return the arm to normal operation.
When AC power is restored, a 1-second pulse is sent to the gate operator input to
automatically restore normal operation.
Must be in the ON position.
2340
DC Magnet
Limit Assembly
(Adjusted at Factory)
Arm Rotation Assembly
in UP Position
DC Limit
Sensor
Arm will cycle to UP
position automatically
during an AC power
failure. DC limit sensor
will hold the arm in
the UP position.
DIP-Switch 3 setting
will determine how
arm will return to
normal operation once
AC power has been
restored.
– +
12 V
3 Amp/Hr
– +
12 V
3 Amp/Hr
Batteries
DC ON/OFF
Power Switch
Red Black
Red/White
Red/White
Red
DC Motor
Black/White
Green to Main Terminal #8
Purple to Main Terminal #5
White to Main Terminal #14
DC Motor Negative Output DC Motor Positive Output Batter
y Negative Input
Batter
y Positive Input
24 V
AC Common
24 V
AC Input
Activation Output Radio Power Not used. Open Input Common
DIP-Switches
