1601-065-L-3-13

15

9410

9410

3.2 Exit Lane Only

Speed Bump

Single Channel

Single Channel

REVERSE
SENSITIVITY

TIME
DELAY

POWER

1

ON

2

3

4

5

6

7

8

1

ON

2

3

4

5

6

7

8

NC NO

UP

LOOP

DOWN

LOOP

1 2 3 4 5 6 7 8 9 10 11 12 13 14

1601

Down Loop

Automatic

Exit Loop

(Free Exit)

SW 1

SW 1, switch 4 is ON.

SW 1, switch 7 is OFF (Timer). The arm will rotate
down after the vehicle clears the down loop.
See note below.

SW 1

SW 2

A

A

Note: The timer can be used with a down loop. When timer is ON with a
down loop, it will start countdown when the arm has fully raised.
Activation of the down loop will cancel timer countdown. Useful when
the automatic exit loop has been activated but vehicle does not move
forward to activate the down loop. The arm will remain UP. Timer will
time out and lower the arm without the down loop being activated.

Helps increase distance
and time between vehicles.

1

ON

2

3

4

5

6

7

8
