Master Mode Analog Setpoint Example
The following example demonstrates Master mode scaling using analog setpoint:
A pump delivers 20.0 gallons per minute when the pump motor rotates
at 1800 RPM. The pump motor is equipped with a 60 tooth ring kit
feedback sensor. The pump will run at 20.0 gallons per minute with an
analog input of 10 volts.
Table 3-13 Master Mode Setpoint Allocation Example
CP Parameter Name Value Remarks
CP-84 Analog Input
Allocation
CP-20 Master Engineering
Units
CP-34 Max RPM Feedback
CP-31 PPR Feedback
Allocates the analog input as
Master Setpoint 1.
This is the Engineering Unit value
that would be present if the analog
input were at 10.0 volts.
The maximum operating RPM of
the feedback shaft.
Feedback sensor resolution.
4
20.0
1800
60
