MONITOR PARAMETERS
Parameters are divided into two classifications; Control Parameters (CP) and Monitor
Parameters (MP). The numbered code that represents the Parameter is the Parameter
Code. The operational data is the Parameter's value.
Control Parameter 05 = 50
(default)
Parameters =
Monitor Parameter 40 = 200
(arbitrary)
Parameter Code Parameter Value
This section is about Monitor Parameters. Control Parameters are explained in
Operation: Control Parameters .
The MLP–Trim has a number of Monitor Parameters (MPs) that monitor the
performance of the MLP–Trim and your system, troubleshoot for problems, and confirm
the wiring and tuning. MPs can be accessed at any time during the MLP–Trim's
operation, including during Run, Jog, R–Stop and F–Stop.
Note: Monitor Parameters are status indicators only - you can not directly affect a MP.
There are four categories of Monitor Parameters:
Input Monitoring.
Output Monitoring.
Performance Monitoring.
Status Monitoring.
In the subsections that follow, the Monitor Parameters are listed according to these
categories.
